eela Audio Reportophone and Hybrids
the tool for the reporter
Eela Audio Reportophones are the standard tool for many radio reporters. Thousands of S20A Reportophones are in daily use all over the world.
Available are 3 versions: S25 for mobile telephone, S20A for one reporter, S24 for 2 reporters.

Reportophone S20A

Reportophone S20A

The S20A Reportophone (The Original!) is an easy to use, full function radio reporter telephone unit. With almost 10.000 units sold all over the world it's known as the radio reporters "Swiss Army knife".

Just connect a studio microphone, a pair of headphones and the telephone line and dial up your studio for a studio link with maximum audio quality.

Reportophone S24+

 Reportophone S24+

The S24+ is is the dual version of the S20A. By using the same microchip technology as in our broadcast desks, we have made a user friendly, flexible outside broadcast unit, suited for working with any type of analog studio link, being telephone or 4 wire in any combination.The mixer section has been extended, with three mic/line inputs, for two reporters and there are extensive communication facilities available.

The build-in LCD display and the soft keys together with the menu structured working modes keep the operation clear and simple. The S24 can be used anywhere because of it's compact and lightweight though rugged construction with battery powering. A power supply for optional mains operation is included.

Reportophone S25 (for the connection of mobiles)

 Reportophone S25 (for the connection of mobiles)

The S25 Reportophone offers the reporter the possibility to connect to the studio from every place were he can use his mobile telephone. It is easy to use, offers very good protection against HF radiation and has the same features as the world famous S20A. Even the layout and function of the knobs is the same.

The audio quality is surprisingly good. You are getting the best possible audio from the 8 bit 8 kHz telephone system. Under normal circumstances you won't hear any distortion due to the radiation of the telephone.
A special application is the use in Advanced Multirate Wideband systems (AMR-WB / G722).

Reportophone S25

 Reportophone S25

This "wideband audio" or "HD Voice" system increases the bandwidth and transmits in the audio frequency range of 50 Hz to almost 8 kHz. In combination with an S25 Reportophone, good microphone and a suitable mobile telephone audio quality improves to an extend that is very close to much larger and more expensive reporter systems.
A number of carriers have rolled out HD voice services based on this G.722 wideband standard. Amongst others KPN in the Netherlands is also offering this system.

The S25 can also be used as a stationary hybrid in areas where no landlines are available.

To connect your mobile telephone to the unit a wide variety of cables is available for Nokia, Apple, HTC, Samsung,
Sony-Ericsson and others.
For a list of available cables click here. Please note that this list is not complete as each week new types of telephones are available on the market



The EA816 is a stationary telephone hybrid for the GSM network. It is an industrial quality quad band GSM module with AMR-WB codec and the facilities for use as a broadcast hybrid.


- For use in areas without cabled telephone connections.

- To make use of the new HD-voice (Advanced Multirate - Wideband) facilities more and more mobile telephone companies are offering. The audio bandwidth is extended from 50 Hz to 7 kHz for a crystal clear sound, ideal for the radio reporter in combination with the S25 Reportophone.

- Depending on your network provider and system used it can be a huge money saver. In a lot of countries a call from mobile to mobile is much cheaper than from mobile to fixed or visa versa. In some situations these calls can even be free of charge.

- For special applications the unit has an auto-answer mode and te possibilty to control an electronic switch from a telephone keypad.
You can also dial a preprogrammed telephone number with an external contact.

- Adjustable echo chancellor for use without cleanfeed or in conference systems.

For more information see .

EELA Audio Telephonehybrid

Telephonehybrid EA 815 electronic

EELA Audio Telephonehybrid

Now in improved new technology, one of the most sold analog hybrids.

The EA815/2 is the latest version of the popular, easy to operate, high quality, analogue telephone hybrid.

 EELA Audio Telephonehybrid

The hybrid has a built-in limiter and bandpass filter and can be used in combination with analogue telephone lines (POTS). Voice Control is used together with preset balance, to achieve the best damping of the send signal. The unit has balanced line in- and outputs on XLR-type connectors and Opto isolated remotes on a D-9 connector. The send and receive gain is adjustable through the front panel.
This latest version comes with a wide range power adaptor (100..240Volts, 50/60 Hz).

Two units can be combined in one 19" rack. Rackmount kits are available as an option.

further details under:
